Cartridge Capping Machine
The automatic cartridge and device capping machine utilizes high-precision motors and constant pressure to ensure flawless capping. With a sealed environment, it prevents oil contamination and minimizes human error, delivering consistent, high-quality results every time. Built with durable, medical-grade stainless steel and advanced control systems, it guarantees hygiene, reliability, and long-term performance. Designed to handle different cartridge and device types, this machine streamlines the sealing process, reduces labor costs, and enhances efficiency for both small-scale and large-scale production needs.
CM-05 Auto Cartridge Capping Machine
Applicable atomizer cartridge length： 20-110mm
Twist Output： 900-1500 sticks / hour
Panel control： Touch screen, operation button, Smart Capping System
Drive mode： Stepper motor + rail drive
Power supply： AC220V/110V
TM03 Auto Cartridge Capping Machine
Applicable atomizer cartridge length： 20-110mm
Export package size (mm) weight： Wooden box packaging L*W*H=650*760*750mm, 80kg
Machine Dimensions W*D*H(mm) weight： 550*660*650mm, 70kg
Panel control： Touch screen, operation button, Smart Capping System
Drive mode： Stepper motor + rail drive
Power supply： AC220V/110V
Output： 800-1000 sticks / hour
FC-01 Automatic Cartridge Filling and Capping Machine
Export package size (mm) weight： Wooden box packaging L*W*H=920*1300*1600mm/350KG
Machine Dimensions W*D*H(mm) weight： 800*800*1400mm/305KG
Productivity of filling and capping： 800-1500 sticks / hour
Oil tank： 500ml/1000ml * 2pcs oil tank
Power supply： AC100V-120V; AC200V-240V
Oil filling accuracy： ±1%
Amount of oiling： 0.2-2ml/5ml
CM03 Automatic capping machine
Panel control： Touch screen, operation button, Smart Capping System
Drive mode： Stepper motor + rail drive + Hydraulic control
Working pressure (Kg)： 10T
height can be adjusted, compatible different carts, pens
Applicable vaporizer device length： 20-120mm
Power supply： 20-120mm
Output： 800-1000 sticks / hour
